Description
Twinwall® are engineered for the toughest of conditions. Twinwall bars feature a patented design that borrows aircraft design principles by utilising two tubes. Providing the rider with a combination of strength, lightweight and safety. Since their introduction in 1998, Twinwall® handlebars have been the handlebar of choice for more professional race teams and have helped more riders win championships than any other handlebar in the world.
FEATURES:
- The Twinwall consists of two aluminium alloy tubes, one within the other. This design gives the handlebar additional strength and security. Making Twinwall the toughest handlebar available.
- The outer tube is made from 7010 T73 aluminium, which has extremely good resistance to mechanical damage and is anodised to prevent corrosion.
- The Twinwall undergoes a 29-step process that sees raw tubing come in and finished handlebars leave the factory.
- Testing plays an important role during the development and production of each Renthal Handlebar.
- Shot peened surface finish helping prevent fatigue failure
- Knurling – Grip end only – increases bonding between bar and grip
- No knurling in the clamp area; this could cause a stress riser and lead to fatigue failure.
- A 15-step anodising process forms an integral coating providing protection against corrosion.
- Renthal’s copyrighted, bonded lightweight single bolt clamping system for the cross-brace, greatly increases strength whilst still allowing flex
- Laser-etched positioning grid
- Every Twinwall bar comes with a Renthal injection-moulded foam bar pad.
DIMENSIONS:
Width A: 813mm
Height B: 79mm
Rise C: 42mm
Clamp Width D: 125mm
Sweep E: 54 mm
Control Length F: 200 mm
Mounting Diameter: 28.6mm or 1+1/8″
