Description
SHV-Series sliding hand valve is a 4-way, 3-position,
manual-operated air valve. Recommended for stationary air
cylinders, arbor presses, and/or as a throttling valve for positioning
air cylinder. The 90˚ lever movement provides reliable switching function by the
rotary disc. The rotary disc is under consistent spring pressure to
provide a leak-proof seal. In center position, inlet is closed to
pressure, and the outlet is closed to exhaust. Each position is
positively detented and the removable handle prevents
unauthorized movement. Unit should be mounted in a protective position, free from excessive vibration. Use of filtered and lubricated air is highly recommended
for maximum valve life and minimum maintenance.
